Quick Overview
The Echelon EX-Pro is a commercial smart bike built for health clubs, YMCAs, universities, hotels, recreational centres, and corporate gyms. A 24-inch class HD touchscreen flips 180 degrees for off-equipment training, 32 levels of electromagnetic resistance cover every ability, and one commercial subscription per bike gives every guest unlimited rides and full access to Echelon content.
- 24″ Class HD Touchscreen that Flips 180°
- 32 Levels of Electromagnetic Resistance
- Heavy-Duty Morse Taper Crank for Years of Smooth Riding
- Ultra-Simple Ratchet Levers for All 4 Seat and Handlebar Adjustments
- SPD-Compatible Pedals and Competition-Style Seat
- Front Wheels and Rear Handle for Mobility
Specs
- Model – ECHEX-PRO
- Power Requirements – 110V or 240V (2 ports, front and rear frame); generator powers the bike resistance system
- Internet Requirements – Ethernet wired or Wi-Fi (download > 25 Mbit/s; upload > 512 Kbit/s)
- Ethernet Connection Port – 2 ports, front and rear
- Touchscreen – 24″ HD touchscreen with 180° pivot adjustment
- Audio – User-facing dual speakers, Bluetooth audio, standard 3.5 mm audio jack
- Workout Data Displayed – Live Leaderboard, Watts, RPM, MPH, Calories, Distance, Time, Heart Rate, Resistance Level
- Heart Rate – Bluetooth telemetry
- Adjustability – Ultra-simple ratchet lever design: seat up/down, seat fore/aft, handlebars up/down, handlebars fore/aft
- Pedals – Heavy-duty commercial-grade SPD clips and toe cage
- Crank – Morse Taper, heavy-duty commercial grade
- Drive System – Kevlar Poly-V power drive belt
- Resistance System – Electronic generator brake
- Safety Brake – Immediate-response electronic safety brake
- Water Bottle Holders – 2, heavy-duty comfort-coated steel
- Dumbbell Holders – Included (weights sold separately)
Dimensions
- Footprint – 57.48″ x 24.40″ x 55.51″ / 145.9 cm x 61.9 cm x 140.9 cm
- Product Weight – 165.34 lbs / 75 kg
- User Height Range – 4’5″ to 6’8″ / 134 cm to 203 cm
- Maximum User Weight – 350 lbs / 159 kg
- Warranty – 2 Years All Parts / 2 Years Labor (Commercial, unlimited use)
